TeraFlex Uinta Cargo Rail System

Description

• High resistance to damage
• Black finish
• Increases loading space

Rail specifications:

• Load capacity up to 225 kg
• Rails made of 6063-T5 aluminum
• Attractive and durable finish
• Powder coated
• Increased corrosion resistance
• Ensures perfect fit of the handles
• End caps made of UV-resistant material and flexible injection-molded high-density polyurethane (HDPE) plastic

Handle specifications:

• Load capacity of a single handle up to 112 kg
• Made of forged 304 stainless steel
• Black anodized 6061-T6 extruded aluminum body and red anodized aluminum knob
• Adjustable knob to secure heavy loads
• The knob has a pressed-in threaded steel stem with an 8mm Allen screw that allows adjustment using an Allen key or socket.
• Attached to the body with 6mm Allen screws, which can be used to attach optional accessories
• A snap ring behind the T-nut on the stud prevents accidental disassembly of the device by preventing the nut from falling into the rail
• More durable than factory ones
• Compatible with factory side rails

Included in the set:

• (1) Uinta Rail Front
• (2) Uinta Rail (Right and Left)
• (6) Uinta Plugs
• (4) Uinta Box Handles
• Mounting kit

Comments:

• No drilling or threading required
• Please remember not to exceed the load of 112 kg per handle.
• Factory brackets are not compatible with this kit.
